AWT Global RFID Protocol Analyzer / Simulator
Description
AWT has introduced the world’s first All-In-One RFID Protocol Analyzer/Simulator. This product is to measure and evaluate the compliance of specifications which are prescribed by ISO 18000 series for the RFID tags or readers including active or passive.
It can provide more convenient test, analysis and evaluation environment for the designers, manufacturers, and service providers related in RFID markets. Using this, you can shorten the development schedule, reduce the cost, and increase the productivity.
Features
- Emulate the Standard RFID Reader or Tag
- Measure and Evaluate RFID Tags and Readers Protocol to check the compliance with ISO 18000 series
- Measurement of Frequency, Power and Modulation
- Display Timing Waveform / Code Data
- Compact Size – Easy to use
Specifications
|
Parameter |
Description |
||
|
Frequency |
Range |
120 kHz – 140 kHz 13 MHz – 14 MHz 430 MHz – 440 MHz 860 MHz – 960 MHz 2.40 GHz – 2.49 GHz |
|
|
Resolution |
10 Hz |
||
|
Tx. |
Output Power Level |
+10 dBm max |
|
|
Level Control |
Range |
30 dB |
|
|
Resolution |
1 dB |
||
|
Rx. |
Sensitivity |
-90 dBm |
|
|
|
Level Measure Range |
-90 – 0 dBm |
|
|
Modulation |
AM, FM, PSK, Back, Scatter, GMSK |
||
|
Coding |
PIE, PPM, Manchester, FM0, Miller, MFM, NRZ |
||
